- The KNX/DALI Gateway communicates with up to 64
- DALI actuators per channel. These can be connected and dimmed in up to 16 groups per channel.
- The gateway also supports selected sensors with DALI interface.
- It also records and transfers DALI status and error messages.
- An individual name, a group, parameter and scenes are assigned to individual DALI ECG´s during commissioning with the ETS (Engineering Tool Software).
- DALI sensors and their functionality are also assigned in the ETS.
- All DALI subscribers and functions are independent and can be linked via group addresses.
- The device can only be operated in DALI segments with connected ECGs and sensors and not with further DALI controllers within the segment (no multi-master mode).
- The power needed for ECGs and sensors is supplied directly through the gateway. An additional DALI power supply is not required, neither is it permitted.
62%
- The device may be used for permanent interior installations in dry locations within distribution boards or small casings with DIN rail EN 60715-TH35.
- To ensure an uninterrupted power supply a separate circuit with safety separation should be used for the power supply unit power supply line.
