• The push button interface is a binary input and output device for installation in in-wall boxes (Æ 60 mm, depth: 40 mm).
• Each of the two channels may be used either as an input for potential-free switch / push button contacts or as an output for control of a light emitting diode (LED).
• The required scanning / control voltage is provided by the push button interface (requires no additional power supply).
• For example, up to 2 switches/push buttons with one potential-free contact each or one 2-fold push button with two potential-free contacts may be connected to a push button interface.
• The connection is carried out via a cable set which is permanently connected to the push button interface.
• The connecting cables between switches/push buttons and the push button interface may be extended up to 10 m. It must be ensured that twisted cable pairs are used.
• Commands can be given to actuators via the connected switches/push buttons, e.g. for defined switching on/off, for dimming fluorescent lamps or for raising/lowering venetian blinds and adjusting the louvres.
• Each channel, which is configured as an output, can drive an output current of up to 2mA for controlling a light emitting diode (LED).
• With the ETS the application program is selected, its parameters and addresses are assigned appropriately, and downloaded to the push button interface.

Mounting plate for presence detector.

• Mounting plate for presence detectors UP 258Dx1 S 258/12

• For mounting presence detector UP 258Dx1 with 4x4 boxes.

• Color white (similar to RAL 9016)
• Dimensions 109x109x11 mm

• Surface mounting box for presence detectors UP 258Dx1 AP 258E11
• For mounting presence detector UP 258Dx1 as a surface-mounted device.
• Color white (similar to RAL 9016)
• Dimensions (LxWxH) 109x109x30 mm

Characteristics

• Actively  emitted by the ultrasound sensor (US), ultrasound waves (40 kHz) propagate around the rest of the room.
• They envelop objects that are in the room and penetrate into all corners.
• This means that the ultrasound sensor (US) can even detect movements when there is no line-of-sight contact between it and the person.
• This presence detector is equipped with an integrated brightness and temperature sensor.
• The maximum detection area is 28 m² for presence and 79 m² for motion.
• The presence detector captures brightness and temperature data and thus controls not only the illumination systems but also ventilation and heating systems.
• Communication is conducted via KNX. The presence detector is designed for installation in the ceiling.

Characteristics

• These presence detectors are equipped with an integrated brightness sensor and HVAC sensors that use multiple calibration methods so that they can be adjusted at the particular installation location.
• The maximum detection area is 64 m² for presence and 400 m² for motion.
• The presence detectors capture brightness, humidity, temperature, brightness and CO2 and thus control not only the illumination systems but also ventilation and heating systems.
• Communication is conducted via KNX. All types are designed for mounting on the ceiling.

Characteristics

• These presence detectors are equipped with an integrated brightness sensor and HVAC sensors that use multiple calibration methods so that they can be adjusted at the particular installation location.
• The maximum detection area is 64 m² for presence and 400 m² for motion.
• The presence detectors capture brightness, humidity, temperature, brightness and CO2 and thus control not only the illumination systems but also ventilation and heating systems.
• Communication is conducted via KNX. All types are designed for mounting on the ceiling.

Characteristics

• These presence detectors are equipped with an integrated brightness sensor and HVAC sensors that use multiple calibration methods so that they can be adjusted at the particular installation location.
• The maximum detection area is 64 m² for presence and 400 m² for motion.
• The presence detectors capture brightness, humidity, temperature, brightness and CO2 and thus control not only the illumination systems but also ventilation and heating systems.
• Communication is conducted via KNX. All types are designed for mounting on the ceiling.

Presence / Motion detector

• The detector senses the presence of a person or that there is no longer anyone in its detection area.
• The detector signal can be analyzed via two separate communication channels, termed motion detector and presence detector.
• The detection range is identical for all channels. Each channel can be locked individually via objects.

HVAC detector

• The detector has an additional control output for HVAC applications.
• For example, this function can switch systems that are used for heating, ventilating and climate control (HVAC) of the room from “Energy saving mode” in an unused room to “Comfort mode” in an occupied room and back to “Energy saving mode”, when the room is again unoccupied.
• Functionality of the Presence detector / Motion detector / HVAC-detector
• For each detector channel 4 communication objects are available, in sum 12 different communication objects.
• It is possible to send one or two KNX telegrams at the beginning and at the end of a detected presence, according to configuration.
• The values of the communication objects are configured for each functional block (motion detector, presence detector, HVAC-detector) via corresponding parameters.

Presence detector with brightness sensor for detection of motion and presence for ceiling mounting

• Contrast measurement of brightness
• Presence motion detection up to Ø8 m
• Flush mounted installation in ceilings with wall box or clamps
• Integrated IR receiver for IR remote control

Functions with commission with ETS

• Three independent output channels with four commands each in case of motion detection
• Integrated 2-level light controller (switching)
• Integrated constant light level controller for up to five lighting groups including
• Usage of motion detector as standalone mode or extension mode to cover wider areas
• Independent output channel for HVAC applications

Presence detector with brightness sensor for detection of motion and presence for ceiling mounting

• Contrast measurement of brightness
• Presence motion detection up to Ø8 m
• Flush mounted installation in ceilings with wall box or clamps
• Integrated IR receiver for IR remote control

Functions with commission with ETS

• Three independent output channels with four commands each in case of motion detection
• Integrated 2-level light controller (switching)
• Integrated constant light level controller for up to five lighting groups including
• Usage of motion detector as standalone mode or extension mode to cover wider areas
• Independent output channel for HVAC applications

The Siemens Industry Gamma Lighting Control Enclosures support Gamma Lighting system components and other panel-mounted devices that snap into DIN rails.

Specially designed to accommodate the different DIN rail-based KNX modules, regardless of the manufacturer.

The following table provides ordering information:

Enclosure Type: UL and cUL Certified NEMA Type 1 Industrial Control Enclosure

• Rated voltage: AC 120 V
• Rated current: 20 A
• Number of channels: 8
• Dimensions (W x H x D): 144 x 90 x 60 mm
• Dimension width (1 MW = 18 mm): 8 MW

• Outputs: Eight outputs (latching relays, potential-free contacts)
• Electrical rating per output:ac/
  • 347 Vac, 50/60 Hz, 15A , cos phi = 1
  • 277 Vac, 50/60 Hz, 20A , cos phi = 1
  • 1.5 HP @ 120 Vac
  • 3 HP @ 277 Vac
• Control voltage: 1 to 10V (provided by ECG Dynamic ballast)
• Dimmable electronic ballast: Maximum 60 units
• Signal amplifier: Maximum 12 units

• Power supply: via KNX Bus line, 20VDC
• Rated voltage: 120V AC +10%/-15%, 50/60 Hz
• Rated current:
  • 2-channel: 2x1.3A@cosФ=1.0
  • 1-channel: 1x2.2A@cosФ=1.0
• N-system DIN-rail mounted device, width:4MU(1MU=18mm)
• Load output:


  Lamp type	2 channels	1 channel
  Incandescent lamps	150 W	250 W
  Low voltage halogen lamps with magnetic transformers	120 VA	200 VA
  Dimmable LED	<= 50 VA	<=50 VA

• The KNX/DALI Gateway communicates with up to 64
• DALI actuators per channel. These can be connected and dimmed in up to 16 groups per channel.
• The gateway also supports selected sensors with DALI interface.
• It also records and transfers DALI status and error messages.
• An individual name, a group, parameter and scenes are assigned to individual DALI ECG´s during commissioning with the ETS (Engineering Tool Software).
• DALI sensors and their functionality are also assigned in the ETS.
• All DALI subscribers and functions are independent and can be linked via group addresses.
• The device can only be operated in DALI segments with connected ECGs and sensors and not with further DALI controllers within the segment (no multi-master mode).
• The power needed for ECGs and sensors is supplied directly through the gateway. An additional DALI power supply is not required, neither is it permitted.

• The device may be used for permanent interior installations in dry locations within distribution boards or small casings with DIN rail EN 60715-TH35.
• To ensure an uninterrupted power supply a separate circuit with safety separation should be used for the power supply unit power supply line.
